ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width

  • ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width
  • ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width
  • ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width
  • ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width
Place of Origin China
Brand Name TISCO BAOSTEEL
Certification SGS BV
Model Number Carbon Steel Sheet
Minimum Order Quantity 1 ton
Price To be negotiated
Packaging Details Kraft paper, wooden case, packaging according to customer requirements
Delivery Time 10-15 days after advance payment
Payment Terms L/C, T/T
Supply Ability 8,000 ton per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name High Quality ASTM A106 Gr.B Seamless Carbon Steel Pipe / ASTM A106 Gr.B Seamless Steel Pipe / A106 Gr.B Steel Pipe Length 1000-12000mm,As Customers' Requirement
Thickness 0.5-100mm,6-400mm,1mm-120mm,0.15mm-300mm Width 600-2500mm,600mm-1250mm,1.8m,305mm/355mm/455mm/510mm
Surface Galvanized Coated,Black Painted,PE Coated,Black Painting Or Galvanized,etc. Material A36 A283 A387 1008 4320 SS400 S235jr
High Light

Black Painting seamless carbon pipe

,

1250mm Width Carbon Steel Pipe

,

ASTM A106 seamless pressure pipe
Leave a Message
Product Description

High quality ASTM A106 Gr.B seamless carbon steel pipe / ASTM A106 Gr.B seamless steel pipe / A106 Gr.B steel pipe





ASTM A106 seamless pressure pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels.

Process

Killed steel, with primary melting process being open-hearth, basic-oxygen, or electric-furnace, possibly combined with separate degassing or refining.

Steel cast in ingots or strand cast is permissible.

Hot-finished pipe need not be heat treated.

Cold-drawn pipe shall be heat treated after the final cold draw pass.



Chemical Composition



Grade A Grade B Grade C
Carbon max. % 0.25 0.30* 0.35*
*Manganese % 0.27 to 0.93 *0.29 to 1.06 *0.29 to 1.06
Phosphorous, max. % 0.035 0.035 0.035
Sulfur, max. % 0.035 0.035 0.035
Silicon, min.% 0.10 0.10 0.10
Chrome, max. % 0.40 0.40 0.40
Copper, max. % 0.40 0.40 0.40
Molybdenum, max. % 0.15 0.15 0.15
Nickel, max. % 0.40 0.40 0.40
Vanadium, max.% 0.08 0.08 0.08





Tensile Requirements



  Seamless
  Grade A Grade B Grade C
Tensile Strength, min., psi 48,000 60,000 70,000
Yield Strength, min., psi 30,000 35,000 40,000





Mechanical Tests Specified

Tensile Test — NPS 8 and larger — either transverse or longitudinal acceptable Smaller than NPS 8 — weighed in lots. Larger sizes — by length. Flattening Test — NPS 2-1/2 and larger. Bending Test (Cold) — NPS 2 and under.

  Degree of Bend   Diameter of Mandrel
For Normal A106 Uses 90   12 x nom dia. of pipe
For Close Coiling 180   8 x nom dia. of pipe





Referenced Documents

  • ASTM A 530/A 530M Specification for General Requirements for Specialized Carbon and Alloy Steel Pipe
  • ASTM E 213 Practice for Ultrasonic Examination of Metal Pipe and Tubing
  • ASTM E 309 Practice for Eddy-Current Examination of Steel Tubular Products Using Magnetic Saturation
  • ASTM E 381 Method of Macroetch testing Steel Bars, Billets, Blooms, and Forgings
  • ASTM E 570 Practice for Flux Leakage Examination of Ferromagnetic Steel Tubular Products
  • ASME B36.10M Welded and Seamless Wrought Steel Pipe

ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width 0



ASTM A106 Seamless Carbon Steel Pipe Black Painting Pressure Tube 1250mm Width 1

Payment Terms

1.Payment: T/T, L/C, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.

2.MOQ: 1pcs

3.Warranty : 3 years

4.Package Informations: 1) EXPORT, In 20 feet (GW 25 ton) or 40 feet Container (GW 25 ton)

2)as customer's requirement



Why choose us?

(1) The leading exporter in China special steel industry.

(2) Large stocks for various sizes, fast delivery date.

(3) Good business relationship with China famous factories.

(4) More than 7 years steel exporting experience.

(5) Good after-sales service guarantee.
