ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape
  • ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape
  • ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape
  • ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape
  • ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape
  • ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape

ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape

Place of Origin China
Brand Name TISCO BAOSTEEL
Certification SGS BV
Model Number Stainless Steel Round Bar
Product Details
Name:
Oxygen Free C10200 C11000 Pure Copper Rod Round Flat Brass Copper Bars
Thickness:
0.5 - 6 Mm,1 - 8 Mm,0.1,10 - 60 Mm,2 - 40 Mm
Standard:
ASTM,DIN,GB,API,BS
Section Shape:
Round, Customizable
Technique:
Hot Rolled,Cold Drawn
Length:
1--12m,1m-6m,as Your Request,6m-12m
Diameter:
12mm-650mm,6-350mm,as Your Requires
Delivery Condition:
Within15 Days After Received The Deposit,within 7 Days
High Light:

C10200 oxygen free copper rod

,

ASTM B98 oxygen free copper rod

,

C11000 pure copper rod

Payment & Shipping Terms
Minimum Order Quantity
1 ton
Price
To be negotiated
Packaging Details
Kraft paper, wooden case, packaging according to customer requirements
Delivery Time
10-15 days after advance payment
Payment Terms
L/C, T/T
Supply Ability
8,000 ton per month
Product Description

Oxygen Free C10200 C11000 Pure Copper Rod Round Flat Brass Copper Bars





Product Description

Product Name
Oxygen Free C10200 C11000 Pure Copper Rod Round Flat Brass Copper Bars
Outside Diameter
0.1mm-500mm
Length
As customer's requirement. normally 2m, 3m, 6m
Bar Shape
Round, Square, Flat, Rectangular, Half Round, Hexagonal
Standard
GB/T 4423-2007, JIS H3250-2006, EN12163-98, JIS H3250, ASTM B150M-03, ASTM B98M-03, ASTM B151M-05,etc
Surface Treatment
Oxidation free treatment, passivation treatment
Hardness
1/16H, 1/8H, 3/8H, 1/4H, 1/2H, H, Soft
Technical
Casting, Extruded
Grade

C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930, C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,TU1,TU2,C12500,

C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,
C26000,C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,
C60800,C63020,C65500,C68700,C70400,C70600,C70620,C71000,C71500,C71520,
C71640,C72200,etc.
Application
Transistor Component Bases, High Resistance-Ratio Cryogenic Shunts, Bus Conductors, Wave Guides, Hollow Conductors, Anodes for Vacuum Tubes, Coaxial Cable, Coaxial Tube, Klystrons, Microwave Tubes, Bus Bars, Lead-in Wire, Vacuum Seals, Conductors, Glass-to-Metal Seals



What is C10100 Copper?





Unalloyed copper or oxygen free coppers have good corrosion resistance and high thermal and electrical properties. Unalloyed coppers of different grades vary based on the amount of impurities present, and have different characteristics. UNS designations of commercially available pure copper are C10100 to C13000. These oxygen free coppers are suitable for applications, which require ductility and high conductivity. C10100 OFHC Copper is produced by the direct conversion of selected refined cathodes and castings under carefully controlled conditions to prevent contamination of the pure oxygen-free metal during processing. The method of producing OFHC copper ensures extra high grade of metal with a copper content of 99.99%. With so small a content of extraneous elements, the inherent properties of elemental copper are brought forth to a high degree.



C10100 Chemical Composition (%)





Cu
Pb
Zn
Fe
P
Ag
As
O
Sb
Min
99.99








Max

0.0005
0.0001
0.001
0.0003
0.0025
0.0005
0.0005
0.004
ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape 0
ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape 1
ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape 2

ASTM B98 Oxygen Free Copper Rod Pure C10200 C11000 Customizable Shape 3




FAQ



Q1. Are you a factory or just a trading company?

A1:We have both factory and trading company,own branch factory and warehouse in Jiangsu,Shandong Province and Tianjin to provide you best price and quality source goods ,and have professional International marketing team to offer you wide range of personalized services.

Q2. What are your company's main products ?

A2: Our main products cover high quality special steel like stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.Hastelloy,Inconel,maraging steel, austenite steel,super duplex stainless steel,carbon steel, copper and aluminum products.

Q3. How do you control quality ?

A3: Mill Test Certification is supplied with shipment, Third Party Inspections are all available.

Q4. What are the advantages of your company ?

A4: We focus on maximum product performance and customer experience with scientific minimum cost,you will get most cost-effective goods.

Q5. How many coutries you already exported ?

A5: Exported to more than 50 countries mainly from Asia countries like Singapore,Indonesia,Vietnam, Bangladesh,Korea,European countries like England,Belgium,Spain,Italy,Russia,Arabian countries like UAE ,Kuwait,Qatar ,Syria,America countries like USA,Mexico,Chili,Peru,South Africa countries... and so on.

Q6. Can you provide sample ?

A6: Small samples in store and can be provided for free without freight. Customized samples will take about 5-7days.
