| Place of Origin | China |
| Brand Name | TISCO BAOSTEEL |
| Certification | SGS BV |
| Model Number | 5182 Aluminum Sheet |
1.6m 5182 Aluminum Sheet Plates Copper 10mm Thick Aluminium Plate
5182 Aluminum Sheet Weldability and resistance to corrosion is considered favorable. This type of alloy is used for body panel sheet because its formability is very good. Resistance to corrosion is good except when material is held at elevated temperatures for long periods of time.
| Elements | Si | Fe | Cu | Mn | Mg | Zn | Others | Al |
| Content | ≤0.20 | 0～0.35 | 0.15 | 0.2～0.5 | 4.0～5.0 | ≤0.25 | 0.05 | Remain |
| Aluminium/ Temper | Specified thickness | Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
| H111-H38 | 0.2-50mm | 173-269 | 66-211 | 4-19 |
1. Strong Corrosion Resistance. Similarly, the surface of 5182 aluminium sheet can form a dense oxide film, which plays a good role in rust prevention, acid resistance, alkali resistance.
2. Strong Weather Resistance. The 5182 aluminum sheet used for the automobile body or building exterior wall is sprayed with special paint or PVDF fluorocarbon paint. The service life up to 25 years and the colour will not fade.
3. High Plasticity. 5182 aluminum sheet/ plate has good forming and processing performance, which can be well adapted to milling, boring, planning and other mechanical processing at the maximum speed that can be achieved by most machine tools.
4. Mechanical Properties. 5182 aluminium sheet tensile strength σb(MPa)≥175, conditional yield strength σ0.2(Mpa)≥80, elongation δ5(%)≥15.
Applications of 5182 Aluminium Sheet
The 5182 aluminum sheet can be used for the car door, Hood, Shipside/bottom plate, deck, refrigeration equipment, tank car, oil tanks, various liquid containers and other low-load parts made by deep drawing. etc.
The standard export packaging, plastic film or craft paper covered at customers’ requirements. Wooden case or wooden pallet is adopted to protect products from damage during the delivery.
As a professional aluminium sheet manufacturer and supplier in China, Shandong Yimao Metal is one of the TOP5 aluminum sheet factories. We are one of the biggest Chinese aluminium sheet suppliers of 5182 aluminium sheet. We also produce aluminium slit coil, aluminium strip, coated aluminium coil, aluminium plate, aluminium sheet metal, anodized aluminium sheet, embossed aluminium sheet, etc.
Shandong Yimao Metal Aluminum provides you with first-rate quality, attractive and reasonable prices. Excellent surface quality and package, fast delivery. If you are looking for a 5182 aluminium sheet supplier in China, Shandong Yimao Metal is your best choice. We promise you the best price and excellent service. For more detailed information, please feel free to contact us directly.
|
Products
|
Alloy
|
Temper
|
Specification (mm)
|
Main Uses
|
|
|
Thickness
|
Width
|
||||
|
1000 Series |
1050, 1060,
1100, 1070,1200, 1235 |
O,H12,H14,H16,H18,H22,H24,H26
|
0.1-300.0 |
20-2800 |
Decoration, cookware
|
|
3000 Series |
3003, 3004,3104, 3105
|
O,H12,H14,H16,H18,H22,H24,H26
|
0.1-300.0 |
20-2800 |
Decoration, cookware
|
|
5000 Series |
5005, 5052,5754, 5083,5454,
5505,5A02, 5A03,5A05 |
O,F,H111,H112,H32,H34,H36,H38
|
0.2-480.0 |
20-2800 |
Aeronautics & Astronautics, Vessel, construction, molding
|
|
6000 Series
|
6061,6063, 6082
|
O,F,H112,T4,T6
|
0.2-480.0
|
20-2800
|
part of machine, electronics & electrics, transportation, etc.
|
|
7000 Series
|
7075, 7475
|
F, T6, T651
|
1-480
|
20-2800
|
Aeronautics & Astronautics
|
|
8000 Series |
8011 |
O, H111, H14, H24, H18
|
0.1-300 |
20-2800 |
Packing, household |
